Specification
| Earth resistance measurement |
20Ω | 200Ω | 2000Ω | |
| Measuring range | 0.00 to 2000 Ω | |||
| Display range | 0.00 to 20.99 Ω | 0.0 to 209.9 Ω | 0 to 2099 Ω | |
| Accuracy*1 | ±1.5%rdg±0.08 Ω*2 | ±1.5%rdg±4dgt | ||
| Auxiliary earth resistance*3 | <10kΩ | <50kΩ | <100kΩ | |
| Comparator reference value | 10Ω | 100Ω | 500Ω | |
| Earth voltage measurement | ||||
| Measuring range | 0 to 300 V AC (45 to 65Hz) ±0 to ±300 V DC |
|||
| Display range | 0.0 to 314.9 V 0.0 to ±314.9 V |
|||
| Accuracy | ±1%rdg±4dgt | |||
| Applicable Standards | IEC 61010-1 CAT Ⅳ 100V / CAT Ⅲ 150V / CAT Ⅱ 300V Pollution degree 3 IEC 61010-2-030, IEC 61010-031, IEC 61557-1, 5 IEC 60529 (IP67), IEC 61326-1, 2-2 |
|||
| Communication interface | Bluetooth®5.0 | |||
| Power source | LR6(AA)(1.5V) × 6 | |||
| Dimension | 121(L) × 188(W) × 59(D) mm (including case lid) | |||
| Weight | Approx. 690g (including batteries and case lid) | |||
| Accessories | 7127B (Simplified measurement probe) 8041 (Auxiliary earth spikes [2spikes/1set]) 9121 (Shoulder strap) 7267 (Cable reel for Earth resistance tester [red:20m]) 7268 (Cable reel for Earth resistance tester [yellow:10m]) 7271 (Earth resistance test lead [green:5m]) 9190 (Carrying case) LR6(AA) × 6, Instruction manual |
|||
| Optional Accessories | 7266 (Earth resistance test leads [red:20m, yellow:10m, green:5m/1set]) 7269 (Earth resistance test leads [red:20m]) 7270 Earth resistance test leads [yellow:10m]) 7272 (Precision measurement Cord set) 8259 (Adapter for measurement terminal) 9197 (Carrying case[Hard]) |
|||
*2 At simplified measurement add ±0.10 Ω to the specified accuracy.
*3 Accuracy within the auxiliary earth resistance: ±5% rdg ±10 dgt.
