Specification
| Insulation Resistance | |
| Test voltage | 250/500/1000V |
| Measuring ranges (Mid-scale value) |
20/200/2000MΩ |
| Output voltage on open circuit | Rated test voltage +20%, -0% |
| Nominal current | 1mA DC min. |
| Output short circuit current | 1.5 mA DC approx. |
| Accuracy | ±1.5%rdg±5dgt (20/200MΩ) ±10%rdg±3dgt (2000MΩ) |
| Continuity Test | |
| Measuring ranges (Mid-scale value) |
20/200/2000MΩ |
| Output voltage on open circuit | 7 to 12V DC |
| Measuring current | 200mA DC min. |
| Accuracy | ±1.5%rdg±5dgt (20Ω) ±1.5%rdg±3dgt (200/2000Ω) |
| AC Voltage | |
| AC voltage range | 0 to 600V AC |
| Accuracy | ±5%rdg±3dgt |
| General | |
| Applicable standard | IEC 61010-1 CAT III 300V Pollution Degree 2 IEC 61010-2-031, IEC 61010-2-034, IEC 61557-1,2,4 IEC 60529 (IP54), IEC 61326-1 (EMC) |
| Power source | R6 (AA) (1.5V) × 8 |
| Dimension | 167(L) × 185(W) × 89(D)mm |
| Weight | Approx. 990g |
| Accessories | 7122B (Test leads) 9074 (Cord case) 8923 (Fuse[0.5A/600V] ) × 1 (included), 1 (spare) R6(AA) × 8 9121 (Shoulder strap) Instruction Manual |
