Specification
| AC A (50/60Hz) | 200mA/2/20/200/1000A ±2.5%rdg±5dgt (200mA/2/20A) ±3.0%rdg±5dgt (200A, 0 to 500A) ±5.5%rdg (501 to 1000A) |
| AC A (WIDE) | 200mA/2/20/200/1000A ±1.8%rdg±5dgt [50/60Hz] (200mA/2/20A) ±2.0%rdg±5dgt [50/60Hz] (200A, 0 to 500A) ±5.0%rdg [50/60Hz] (501 to 1000A) |
| Crest factor | 3.0 or less |
| Conductor size | φ68mm max. |
| Frequency response | 40Hz to 1kHz |
| Output | Waveform :AC200mV against the maximum value of each range (1000A range is 100mV) Recorder :DC200mV against the maximum value of each range (1000A range is 100mV) |
| Applicable standards | IEC 61010-1 CAT III 300V Pollution degree 2 IEC 61010-2-032 |
| Power source | 6F22 (9V) × 1 *Continuous measuring time: Approx. 60 hours |
| Dimension | 250(L) × 130(W) × 50(D)mm |
| Weight | Approx. 600g (including battery) |
| Accessories | 9094 (Carrying Case) 6F22 × 1 Instruction Manual |
| Optional Accessories | 7073 (2WAY Output Cord) |
