| AC A (50/60Hz) | 20/200mA/200A ±3%rdg±5dgt (20/200mA/100A) ±5%rdg±5dgt (200A) |
| AC A (WIDE) | 20/200mA/200A ±2%rdg±4dgt [50/60Hz] (20/200mA/0 to 100A) ±5%rdg±6dgt [40 to 400Hz] (20/200mA/0 to 100A) ±5%rdg±4dgt [50/60Hz] (100.1 to 200A) |
| Conductor size | φ24mm max. |
| Frequency response | 40 to 400Hz |
| Effect of external stray magnetic field φ15mm 100A | 10mA AC max. |
| Safety Standard | IEC 61010-1 CAT III 300V IEC 61010-2-032 |
| Power source | LR44 (1.5V)× 2 |
| Dimension | 149(L)× 60(W) × 26(D)mm |
| Weight | Approx. 120g (including battery) |
| Accessories | 9090 (Carrying Case) LR44 × 2 Instruction Manual |
鉗形表
MODEL 2431真有效值鉗形表
MODEL 2431真有效值鉗形表
- 頻率選擇開關可消除諧波干擾，提高量測準確性
- 自動關機功能，節省電力並延長電池壽命
- 旋轉式開關設計，單指即可開機並選擇量測範圍
- 最小解析度達0.01mA，適合微小電流精密檢測
- 自動關機功能，節省電力並延長電池壽命
- 旋轉式開關設計，單指即可開機並選擇量測範圍
- 最小解析度達0.01mA，適合微小電流精密檢測
詳細介紹
