Specification
| Current measurement | AC A 0 to 100.0A ±2.0%rdg±5dgt [50/60Hz] DC A 0 to ±100.0A ±2.0%rdg±5dgt |
| Crest factor | 2.5 |
| Non contact voltage | Detect AC voltage without contacting with socket wire. During voltage detection, "Hi" flashes and a buzzer sounds. |
| Maximum digit | 1,049 |
| Conductor size | Max φ10mm |
| Safety Standard | IEC 61010-1 CAT III 300V Pollution degree 2 |
| Power source | R03 (AAA)(1.5V)× 2 (Auto power off: Approx.10 minutes) *Continuous measuring time: AC A Approx. 46 hours, DC A Approx. 52 hours |
| Dimension | 161(L) × 40(W) × 30(D)mm |
| Weight | 110g (including battery) |
| Accessories | 9113 (Carrying Case) R03 (1.5V) × 2 Instruction Manual |
