Specification
| AC A | 400/2000A (0 to 1000A) ±1.5%rdg±2dgt [50/60Hz] ±3%rdg±4dgt [40 to 500Hz] ±5%rdg±4dgt [500Hz to 1kHz] 2000A (1001 to 1999A) ±3%rdg±2dgt [50/60Hz] |
| DC A | 400/2000A ±1.5%rdg±2dgt |
| AC V | 400/750V ±1.5%rdg±2dgt [50/60Hz] ±1.5%rdg±4dgt [40Hz to 1kHz] |
| DC V | 400/1000V ±1%rdg±2dgt |
| Ω | 400/4000Ω ±1.5%rdg±2dgt |
| Continuity buzzer | Buzzer sounds below 50±35Ω |
| Conductor size | Ø55mm max. |
| Frequency response | 40Hz to 1kHz |
| Output | Recorder : DC400mV against AC/DC400A DC200mV against AC/DC2000A |
| Safety Standard | IEC 61010-1 CAT IV 600V / CAT III 1000V IEC 61010-031 , IEC 61010-2-032 |
| Power source | R6 (AA) (1.5V) × 2 |
| Dimension | 250(L) × 105(W) × 49(D)mm |
| Weight | Approx. 530g |
| Accessories | 7107A (Test leads) 9094 (Carrying Case) R6 (AA) × 2 , Instruction Manual |
| Optional Accessories | 7256 (Output cord) |
