Specification
| DC V | 0.3V (16.7kΩ/V) ±3% of FS 3/12/30/120/300/600V (20kΩ/V) ±3% of FS |
| AC V | 12V (9kΩ/V) ±4% of FS 30/120/300/600V (9kΩ/V) ±3% of FS |
| DC A | 60µA/30/300mA ±3% of FS |
| Ω | 3/30/300kΩ ±3% of scale length |
| Continuity buzzer | Buzzer sounds below 100Ω |
| Battery test | 1.5V (0.7 to 2V) ±3% of FS (10Ω load) |
| Temperature | Possible with the temperature probe 7060 (discontinued). |
| LED | Approx. 10mA at 0Ω (at 3V of battery voltage) |
| Applicable standards | IEC 61010-1 CAT III 300V / CAT II 600V Pollution Degree 2 IEC 61010-2-031 |
| Power source | R6 (AA) (1.5V) × 2 |
| Dimension | 140(L) × 94(W) × 39(D) mm |
| Weight | Approx. 280g |
| Accessories | 7066A (Test leads) 8923 (Fuse[0.5A/600V]) × 1 (included), 1 (spare) 9103 (Carrying case) R6 (AA) × 2 Instruction Manual |
